This 2-piece Heim joint kit is a great solution for building adjustable suspension or steering components in off-road and custom fabrication projects.
Included in the kit:
-
(1) Left-Hand (LH) and (1) Right-Hand (RH) 3/4" bore Heim joint with 3/4"-16 threaded shanks
-
(2) Weld-in tube bungs for 1.25" ID tubing
-
(2) Jam nuts to lock your setup in place
The RH/LH thread combo allows for turnbuckle-style adjustability—fine-tune your link length without removing it from the vehicle. Ideal for tie rods, drag links, 4-link arms, and more.
? What’s Included
-
(1) RH 3/4" Bore x 3/4"-16 Shank Heim Joint
-
(1) LH 3/4" Bore x 3/4"-16 Shank Heim Joint
-
(2) Weld-In Tube Bungs – Fits 1.25" ID Tubing
-
(2) Jam Nuts – 1 RH & 1 LH
? Specifications
-
Bore Size: 3/4"
-
Thread Size: 3/4"-16 (RH & LH)
-
Shank Type: Standard Length
-
Tube Fitment: 1.25" Inner Diameter
-
Material: High-Strength Steel (Heim + Bung)
-
Finish: Zinc-Plated or Raw Steel
-
Use: Off-Road Suspension & Steering Fabrication
✅ Applications
-
Tie Rods & Drag Links
-
Short Control Arms or 4-Link Bars
-
Adjustable Suspension Links
-
Rock Crawlers, Ultra4, Mud Trucks, SxS
-
Custom Off-Road Builds
